Laser Camera Sensors

ProH Laser Sensor

The intelligent digital laser and camera metal level sensor family from Precimeter is a high performance laser triangulation device developed specifically for its purpose. It will measure on any molten metal surface with a surface temperature below 1000˚C.

arrow icon
Precise level measurement
High performance laser triangulation technology
arrow icon
Secure castings
Automatic castings with minimal human contact
arrow icon
Complete overview
Adjust levels remotely with control system
arrow icon
Control in every step
Stable readings in reflective and harsh conditions

The sensor for every casting

The Laser Camera Sensor model ProH from Precimeter combines high performance laser triangulation with the necessary control functions to maintain an accurate molten metal level measurement. The digital camera technology in the Precimeter sensors results in very high performance and resolution. The advanced technology enables stable readings even when the molten metal material reflectivity changes dramatically and/or in harsh conditions with heavy steam and smoke environment. The built in PI controller eliminates the need for an external industrial controller.

Advantages with ProH Laser Camera Sensor

Technical Specifications

Power Requirement
24 VDC < 1 A
Level Output
4–20 mA
Internal Temp Output
4–20 mA (0–100°C, 32–212°F)
Digital Input
Light source on/off
Digital Output
Sensor status
±0.07 mm
Ethernet Protocol
Optional (Profinet, Ethernet IP or Modbus TCP)
Precimeter tool (PC software)
Laser Power
< 1 mW (Laser class 2) / < 5 mW (Laser class 3R)
Compressed air (3/8” connection)

sensor models

Sensor Model
ProH CD240R325
ProH CD450R300
ProH CD700R300
ProH CD900R500
ProH CD800R1500
ProH CD1500R1600
ProH CD2350R3000
Clearance Distance
240 mm (9.4”)
450 mm (17.7”)
700 mm (27.6”)
900 mm (35.4”)
800 mm (31.5”)
1500 mm (59.0”)
2350 mm (92.5”)
Measurement Distance
325 mm (12.8”)
300 mm (11.8”)
300 mm (11.8”)
500 mm (19.7”)
1500 mm (59.0”)
1600 mm (62.9”)
3000 mm (118.1”)
